Product Features
Applications
The TPU is Horizontal single stage centrifugal pump,designed for gardening use, it is suitable to carry fluids such as water:
Fishery and transport Sea water
Gardening or greenhouse sprinkler system
Transport clean water (Aquaculture / industry)
Pump Construction
Horizontal single stage centrifugal pump, self-priming, co-axial pump/motor design, impellers mounted on extended motor shaft. Main working parts made by stainless steel and engineering plastics.
Motor
Enclosure protection class：IP54
Insulation class：F.
Nominal speed：3500 rpm
Frequency range：60 Hz
Voltages code：61R PH 1~ 60Hz 200-240V
Voltages code：9V PH 3~ 60Hz 200-240 / 380-440V
Operating Conditions
Ambient Temperature: Max. +40°C
Liquids Temperature: +4°C ~ +40°C
System Pressure: Max. 3 kg/cm²
Inlet Pressure: Max. 0 kg/cm²
Max. Suction Depth: 6m
Kinematical Viscosity: 1cst(mm²/s)
Standard Mode
TPU
Compare Products
| Type |
| TPU1100 |
| TPU1500 |
Dimensions(mm)
TPU Series
i.Catalog
Catalog
Self Priming Pump
Updated on 2024/04/16
1.57MB
Thank you TPU Series products !
