Suitable Liquids

Potable water or other clean, thin or non-aggressive liquids.

Product Feature

The HQ_B is a complete, all-in-one unit, consisting of pump, motor, pressure tank, and electronic controller. The built-in electronic controller provides constant pressure which ensures that the pump starts automatically when water is consumed and operates continuously until water is not required.

Compact design and quiet operation make the HQ_B series suitable for many applications. The HQ_B is constructed from the top quality corrosion resistant materials.

The HQ_B is constructed from the top quality corrosion resistant materials.

Pump has built in dry-run shut off with automatic reset function.

The motor has built-in thermal overload to protect against high operating temperatures and over current.

The HQ_B has an anti-cycling feature which prevents the pump from continuous starting and stopping when you have a dripping tap or minor leak in the system.

The pumps will lift water up to 7.6m. with foot valve and pump suction piping filled with water.

Operating Condition

Ambient temperature: Max. +40°C

Liquid temperature: +4°C ~ +40°C

System Pressure : Max. 8.5 kg/cm²

Relative humidity: Max. 85% (RH)

Under normal operation, it is not necessary to adjust the pressure unless the cut in pressure is higher than preset activation point (refer to specification).

HQ_B Series 50Hz

Compare Products

Type
HQ200B
HQ400B
HQ800B
Type Power
(kW)
Phase
(Ø)
Cycle
(Hz)
Volts
(V)
Ampere
(A)
Inlet
(in.)
Outlet
(in.)
Preset Activation
(kg/cm²)
Maximum Head
(M)
Maximum Capacity
(L/min)
N.W.
(kg)
G.W.
(kg)
Maximum Pallet Amount
HQ200B 0.18 1 50 200-240 1.5 1" 1" 1.6 24 55 7.4 8.0 36
HQ400B 0.37 1 50 200-240 2.8 1" 1" 2.0 31 85 8.4 9.0 36
HQ800B 0.75 1 50 200-240 4.5 1" 1" 2.0 33 110 10.8 11.4 36

HQ_B Series 60Hz

Compare Products

Type
HQ200B
HQ400B
HQ800B
HQ800HB
Type Power
(kW)
Phase
(Ø)
Cycle
(Hz)
Volts
(V)
Ampere
(A)
Inlet
(in.)
Outlet
(in.)
Preset Activation
(kg/cm²)
Maximum Head
(M)
Maximum Capacity
(L/min)
N.W.
(kg)
G.W.
(kg)
Maximum Pallet Amount
HQ200B 0.18 1 60 110/220 4.0/2.0 1" 1" 1.6 23 60 7.3 8.6 36
HQ400B 0.37 1 60 110/220 6.0/3.0 1" 1" 1.8 26 80 8.3 9.6 36
HQ800B 0.75 1 60 110/220 10/5.0 1" 1" 2.0 27 120 10.7 12.1 36
HQ800HB 0.75 1 60 110/220 10/5.0 1" 1" 2.5 45 100 10.8 12.2 36

Dimensions (mm)

Model Cycle (Hz) Dimensions (mm)
A B C
HQ200B 50/60 355 153 158
HQ400B 50/60 355 153 158
HQ800B 50/60 410 162 167
HQ800HB 60 410 162 167
