Product Feature

Multistage design provides steady, quiet and vibrationfree operation for years of trouble-free service.

Close coupled, space saving design provides easy installation.

All parts in contact with water are made from corrosion resistant materials.

The pump is installed with thermostat protection switch to protect against dry running. The pump will shut off when water temperature exceeds 130°F (55°C).

The motor has a built-in thermal overload to protect against high operating temperatures and over current.

The pumps will lift water up to 7.6m. with foot valve and pump suction piping filled with water

Operating Condition

Ambient temperature: Max. +40°C

Liquid temperature: +4°C ~ +40°C

System Pressure : Max. 8.5 kg/cm²

Specification, 50Hz

Compare Products (multiple options available)

Type
HS400
HS800
Type Power
(kW)
Voltage
(V)
Ampere
(A)
Inlet
(in.)
Outlet
(in.)
Maximum Head
(M)
Maximum Capacity
(L/min)
N.W.
(kg)
HS400 0.37 200~240 2.8 1" 1" 31 85 8.2
HS800 0.75 200~240 4.5 1" 1" 33 110 11

Specification, 60Hz

Compare Products (multiple options available)

Type
HS400
HS800
Type Power
(kW)
Voltage
(V)
Ampere
(A)
Inlet
(in.)
Outlet
(in.)
Maximum Head
(M)
Maximum Capacity
(L/min)
N.W.
(kg)
HS400 0.37 110/220 6.0/3.0 1" 1" 36 75 8.2
HS800 0.75 110/220 9.0/4.5 1" 1" 46 105 11

Dimensions (mm)

Model Cycle (Hz) Dimensions (mm)
A B C
HS400 50/60 292 91 96
HS800 50/60 344 96 101


i.Catalog

Catalog

HS Series Multistage Centrifugal Pump

Updated on 2021/12/20

ii.Instruction Manual

Instruction Manual

HS Series Instruction Manual

Updated on 2021/12/20
